SENNHEISER EW352-G3-B

Full description

Sennheiser ew 512 G3 system includes the MKE 2-ew: based on the MKE 2 Gold, it is one of Sennheiser's most successful and trusted clip-on condenser microphones. This set relays its high-quality signal via a compact bodypack transmitter to the flagship evolution EM 500 true diversity receiver. Sync up the bodypack to the receiver with a simple press of the sync button. Sennheiser's technical prowess in wireless technology allows you to focus on delivering your most successful presentation ever without worrying about your wireless.

Features:

• High-quality true diversity reception
• Pilot tone squelch for eliminating RF interference when transmitter isturned off
• Automatic frequency scan feature searches for available frequencies
• Enhanced AF frequency range
• Increased range for audio sensitivity
• 42 MHz bandwidth: 1680 tunable UHF frequencies for interference-freereception
• Enhanced frequency bank system with up to 32 compatible frequencies
• Ethernet port for connecting to the Wireless Systems Manager (WSM)software for control via computer - this delivers a good overview ofmonitoring and professional data management for multi-channel systems
• Sturdy metal housing (transmitter and receiver
• Wireless synchronization of transmitter parameter from receiver
• User-friendly menu operation with more control options
• Illuminated graphic display, receiver also shows transmitter settings
• Auto-Lock function avoids accidental changing of settings
• HDX compander for crystal-clear sound
• Transmitter feature battery indicatation in 4 steps, also shown onreceiver display
• Programmable Mute function
• Integrated Equalizer and Soundcheck mode
• Contacts for recharging BA 2015 accupack directly in the transmitter
• Wide range of accessories adapts the system to any requirement

Includes:

• 1 EM 500 G3 rack-mount receiver
• 1 SK 500 G3 bodypack transmitter
• 1 MKE 2-ew clip-on microphone (omni-directional)
• 1 GA 3 rack mount
• 1 NT 2 power supply unit
• 2 antennas
• 2 AA batteries
• Operating instructions

Specifications:

• RF frequency range: 626-668 MHz
• Transmission/receiving frequencies: 1680
• Presets: 32
• Switching bandwidth: 42 MHz
• Peak deviation: +/- 48 kHz
• Compander: HDX
• Frequency response (microphone): 80.....18000 Hz
• Signal-to-noise ratio: > 115 dB(A)
• THD, total harmonic distortion: < 0,9 %
• In compliance with: ETS 300422 , ETS 300445 , CE , FCC
• Antenna connector: 2 BNC, 50 Ohm
• Audio-XLR connector: 6,3 mm
• Audio output level (balanced): XLR: +18 dBu max
• Audio output level (unbalanced): Jack: +12 dBu max
• Dimensions (Receiver): 212 x 202 x 43 mm
• Weight (Receiver): 980 g
• RF output power: 10/30 mW
• Operating time (transmitter): > 8 h
• Input voltage range: 1,8 V, line
• Input voltage range: 3,0 V eff line
• Dimensions (Transmitter): 82 x 64 x 24 mm
• Weight (Transmitter): ~ 160 g
• Transducer; Microphone type: elektret
• AF sensitivity: 6,3 mV/Pa
• Sound pressure level (SPL): 142 dB(SPL) max.
• Pick-up pattern: omni- directional
