Lilliput PVM220S

Descriptions détaillées

The PVM 220S is a 21.5 inch live stream multiview monitor which can be used with Android mobile phones, DSLR cameras and camcorders and is particularly designed to work with streaming & multi camera systems. The live monitor can be switched between 4x 1080P high quality video signal inputs, making it easy to create professional multi-camera events for live streaming.
Sources can be set up as Preview and Finished Program, and you can quickly switch your source for live streaming to video capture via a number ofshortcuts, and then finally output the completed video to Youtube, Skype, Zoom and any more social media platforms.


Specification

Display

• Aspect Ratio : 16:9
• Brightness : 500 nit
• Contrast Ratio : 1500:1
• Resolution : 1920 x 1080
• Viewing Angle : 170° / 170° (H/V)
• Screen Size : 21.5"

Inputs

• SDI Video Inputs : 2160p 24 / 25 / 30 / 50 / 60 :: 1080p 24 / 25 / 30 / 50 / 60 :: 1080i 50 / 60 :: 720p 50 / 60
• HDMI Video Inputs : 2160p 24 / 25 / 30 / 50 / 60 :: 1080p 24 / 25 / 30 / 50 / 60 :: 1080i 50 / 60 :: 720p 50 / 60 + PGM HDMI/SDI × 1 1080p 60/50/30/25/24

Size

• Dimensions : 508mm × 321mm × 47mm
• Weight : 5.39 Kg

Power

• Audio Output : 1x Speakers + 1x Earplug Jack
• Input Voltage : DC 12-24V
• Power Consumption : <=33W (15V)

Environment

• Operating Temperature : -20°c to 60°c
• Storage Temperature : -30°c to 60°c
